Détails du produit
Technical characteristics
Module | |
LED encapsulation | 1515 |
Pixel Pitch | 2.6 mm |
Module resolution (W x H) | 96 x 96 |
Module size | 250 x 250 mm |
Cabinet | |
Module quantity per cabinet (W x H) | 2 x 2 |
Cabinet resolution (W x H) | 192 x 192 |
Cabinet size | 500 x 500 x 65 mm |
Cabinet area | 0.25 m2 |
Weight | 5.6 (kg/cabinet) |
Pixel density | 147,456 (dot/m2) |
IP grade | IP20 |
White balance brightness | 3500 - 4000 nit |
Color temperature | 6500 - 10,000 K adjustable |
Horizontal viewing angle | 160° |
Vertical viewing angle | 145° |
Electrical parameters | |
Power consumption | 450 / 150(W/m2) |
Working voltage | 100 - 240 VAC 50/60 Hz |
Processing Performance | |
Driving method | constant drive |
Scanning method | 1/24 s |
Frame frequency | 50 & 60 Hz |
Refresh frequency | 1920 - 3840 Hz |
Control system | Nova Star |
Usage parameter | |
Life span | 80,000 h |
Working / storage temperature | -20 to 45 °C / -30 to 60 °C |
Working / storage humidity (RH) | 10 - 90% / 10 - 90 % (no condensation) |
Communication Mode | CAT5 |
Certification | CE FCC ETL |
