SKU: P2.6MWI21

Yes Tech - P2.6 Mwall

Name: P2.6 Mwall
Brand: Yes Tech
SKU: P2.6MWI21
Price: 420 EUR
Availability: OutOfStock

Indoor, fixed installation only, IC DP3265, SMD1515, full black LED, copper wire, Nova A5S Plus, module flash function, 800 - 1000 nit, ≤3840 Hz, 500 x 500 mm, 6 kg

(0)

700,00 €

- 40%

420,00 €

Pay in 4 interest-free payments of 105,00 € with Discover More

La quantité sélectionnée est supérieure à celle disponible en stock. Pas de problème ! Nous procéderons en vous envoyant immédiatement la quantité disponible. Nous vous enverrons ensuite le solde, sous 10 jours environ.

Unfortunately, the quantity you have selected exceeds the amount available in stock.

Condition : Neuf

J'accepte les conditions générales et la politique de confidentialité

Not available.

delivery is not available for this product.

Livraison gratuite pour toute commande égale ou supérieure à 199 € sont limités à la livraison au sein de l'Europe

Variants of this product

Yes Tech - P2.6 MG13

932,50 €

(0)

Sector display indoor, IC ICN2153, SMD1515, full black LEDs, copper wire, 800 - 1000 nit, ≤3840 Hz, 500 x 500 mm, 5 kg

EGO Display - EasyPRO-P2.5

120,50 €

(0)

Indoor, front service, SMD1515, 800 nit, 3840 Hz, 320 × 480 mm, 2.1 kg

EGO Display - EasyFLEX-P2.5-100

455,00 €

(0)

Indoor, 3-in-1 SMD, 800 nit, 5000:1, ≥ 3840 Hz, 500 x 1000 mm, 10 kg high-performance LED panel, flexible design, right angle splicing for option

Yes Tech - P2.6 XTRA Indoor

707,50 €

(0)

Indoor, SMD1415 black LEDs, 800 - 1200 nit, 3840 - 7680 Hz, 500 x 500 mm, 7.5 kg

Yes Tech - P2.6 Mwall A10PRO

482,50 €

(0)

Indoor, fixed installation only, IC DP3265, SMD1515, full black LED, copper wire, Nova A10PRO, HDR 10, module flash function, 800 - 1000 nit, 3840/7680 Hz, 500 x 500 mm, 6 kg

EN Instruction Manual (4.47MB)

NO DESC

Documentation

EN Instruction Manual (4.47MB)

NO DESC

Documentation

Watch it in action

Close the video

Détails du produit

Technical characteristics

Module
LED encapsulation	1515
Pixel Pitch	2.6 mm
Module resolution (W x H)	96 x 96
Module size	250 x 250 mm
Cabinet
Module quantity per cabinet (W x H)	2 x 2
Cabinet resolution (W x H)	192 x 192
Cabinet size	500 x 500 x 65 mm
Cabinet area	0.25 m²
Weight	5.6 (kg/cabinet)
Pixel density	147,456 (dot/m²)
IP grade	IP20
White balance brightness	800 - 1000 nit
Color temperature	6500 - 10,000 K adjustable
Horizontal viewing angle	160°
Vertical viewing angle	145°
Electrical parameters
Power consumption	450 / 150（W/m²）
Working voltage	100 - 240 V_AC50/60 Hz
Processing Performance
Driving method	constant drive
Scanning method	1/24 s
Frame frequency	50 & 60 Hz
Refresh frequency	1920 - 3840 Hz
Control system	Nova Star
Usage parameter
Life span	80,000 h
Working / storage temperature	-20 - 45 °C / -30 - 60 °C
Working / storage humidity (RH)	10 - 90% / 10 - 90 % (no condensation)
Communication Mode	CAT5
Certification	CE, FCC, ETL
