SKU: P2.6MWI21

Yes Tech - P2.6 Mwall

Indoor, fixed installation only, IC DP3265, SMD1515, full black LED, copper wire, Nova A5S Plus, module flash function, 800 - 1000 nit, ≤3840 Hz, 500 x 500 mm, 6 kg
700,00 €
- 40%

420,00 €

Pay in 4 interest-free payments of 105,00 € with Discover More

La quantité sélectionnée est supérieure à celle disponible en stock. Pas de problème ! Nous procéderons en vous envoyant immédiatement la quantité disponible. Nous vous enverrons ensuite le solde, sous 10 jours environ.
Unfortunately, the quantity you have selected exceeds the amount available in stock.
Condition : Neuf

Not available.

delivery is not available for this product.

Livraison gratuite pour toute commande égale ou supérieure à 199 € sont limités à la livraison au sein de l'Europe



EN Instruction Manual (4.47MB)

NO DESC

Documentation

Watch it in action

Video Youtube
Close the video

Détails du produit

Technical characteristics

Module
 LED encapsulation   1515
 Pixel Pitch  2.6 mm
 Module resolution (W x H)  96 x 96
 Module size  250 x 250 mm
Cabinet
 Module quantity per cabinet (W x H)  2 x 2
 Cabinet resolution (W x H)  192 x 192
 Cabinet size  500 x 500 x 65 mm
 Cabinet area  0.25 m2
 Weight  5.6 (kg/cabinet)
 Pixel density 147,456 (dot/m2)
 IP grade   IP20
 White balance brightness   800 - 1000 nit
 Color temperature  6500 - 10,000 K adjustable
 Horizontal viewing angle  160°
 Vertical viewing angle  145°
Electrical parameters
 Power consumption  450 / 150(W/m2
 Working voltage  100 - 240 VAC 50/60 Hz
Processing Performance
 Driving method  constant drive
 Scanning method  1/24 s
 Frame frequency  50 & 60 Hz
 Refresh frequency  1920 - 3840 Hz
 Control system  Nova Star
Usage parameter
 Life span  80,000 h
 Working / storage temperature  -20 - 45 °C / -30 - 60 °C
 Working / storage humidity (RH)  10 - 90% / 10 - 90 % (no condensation)
 Communication Mode  CAT5
Certification  CE, FCC, ETL
