SKU: P3.9MG7SO21-CW-U

Yes Tech - P3.9 MG7S-CW

Outdoor, IC DP3265 SMD1515, black shell LEDs, copper wire, 4200 - 4500 nit, ≤3840 Hz, 500 x 500 mm, 6.5 kg

462,50 €

Pay in 4 interest-free payments of 115,63 € with Discover More

3 articles disponibles dans notre entrepôt italien

La quantité sélectionnée est supérieure à celle disponible en stock. Pas de problème ! Nous procéderons en vous envoyant immédiatement la quantité disponible. Nous vous enverrons ensuite le solde, sous 10 jours environ.
Unfortunately, the quantity you have selected exceeds the amount available in stock.
462,50 €
Condition : Usagé

Prime

livraison rapide est disponible pour ce produit.

Ce produit est disponible dans nos entrepôts en Italie, il sera donc livré dans un délai de 2 à 5 jours ouvrables.

Livraison gratuite pour toute commande égale ou supérieure à 199 € sont limités à la livraison au sein de l'Europe



EN Instruction Manual (11.32MB)

NO DESC

Documentation

LED Screen Maintenance (42.64KB)

NO DESC

Documentation

Détails du produit

Technical characteristics

Module
LED encapsulation  1515 black shell LED
Pixel pitch  3.9 mm
Module resolution (W x H)  64 x 64
Module size  250 x 250 mm
Cabinet
Module quantity per cabinet (W×H)  2 x 2
Cabinet resolution (W x H)  128 x 128
Cabinet size   500 x 500 x 73 mm
Cabinet area  0.25 m2
Weight   7.4 kg/cabinet
Pixel density  65536 dot/m2
IP grade  IP65
White balance brightness  4200 - 4500 nit
Color temperature  6500 - 10,000 K adjustable
Horizontal viewing angle  160°
Vertical viewing angle  160°
Contrast ratio  6000:1
Electrical parameters
Power consumption  600 / 200 W/m2
Power supply  Megmeet
Working voltage  100 - 264 VAC 50/60 Hz
Processing performance
Driving method  constant drive
Scanning method  1/11
Driving IC  DP3265
Receiving card  Nova A5S+
Refresh frequency  ≤ 3840 Hz
Control system  Nova Star
Usage parameter
Life span  80,000 h
Working / storage temperature    -20 to 45 °C / -30 to 60 °C
Working / storage humidity  10 - 90% / 10 - 90% RH (no condensation)
Communication mode  CAT5
Certification  CE FCC ETL
