Blackmagic Design - Mini Converter - SDI to Analog 4K

Name: Mini Converter - SDI to Analog 4K
Brand: Blackmagic Design
SKU: CONVMASA4K
Price: 329 EUR
Availability: OutOfStock

SDI to analog down-converter with audio

(0)

329,00 €

(IVA esclusa)

Pay in 3 interest-free payments of 109,67 € with Discover More

Unfortunately, the quantity you have selected exceeds the amount available in stock. No problem! We will go ahead and send you the available quantity. We will then send you the reminder approximately within ten days.

Unfortunately, the quantity you have selected exceeds the amount available in stock.

Condizione: Nuovo

Enim quis fugiat consequat elit minim nisi eu occaecat occaecat deserunt aliquip nisi ex deserunt.

Non disponibile

spedizione non disponibile per questo prodotto.

La spedizione gratuita per tutti gli ordini uguali o superiori a 199 € è limitata alle spedizioni all'interno dell'Europa

Varianti di questo prodotto

Blackmagic Design - Teranex Mini - Smart Panel

80,50 €

(0)

Front panel control for Teranex Mini

Blackmagic Design Teranex Mini - Smart Panel

Datavideo - DAC-70

516,50 €

(0)

Ultra-wide range video scaler, VGA / HDMI / SDI to HDMI / SDI, multi-format up / down / cross

Blackmagic Design - ATEM Camera Converter

555,00 €

(0)

Optical fiber converter with Talkback, Tally and MIC inputs, internal battery

Blackmagic Design - Mini Converter

330,50 €

(0)

3G-SDI to fiber converter, bidirectional

Datavideo - DAC-90

314,00 €

(0)

SDI Audio De-embedder

Watch it in action

Close the video

Dettagli Prodotto

Mini Converter SDI to Analog 4K è un convertitore che trasforma segnali SD, HD, 3G e 6G‑SDI in uscite analogiche component HD/SD, NTSC e PAL. Grazie al down‑converter integrato, consente di collegare sorgenti Ultra HD a dispositivi analogici tradizionali, garantendo compatibilità immediata con monitor, registratori e sistemi legacy.

Supporta un’ampia gamma di apparecchiature analogiche come Betacam SP, VHS e monitor video, offrendo una soluzione affidabile per integrare tecnologie moderne con infrastrutture esistenti. Compatto e robusto, è ideale per ambienti broadcast, post‑produzione e installazioni AV che richiedono massima flessibilità e qualità del segnale.

Technical characteristics

Connections

SDI video inputs: 1 x SD, HD or 6G‑SDI. 1 x ALT SDI Input for automatic switch over if main input fails
SDI video outputs: 1 x SDI loop output
Analog video outputs: NTSC, PAL, S‑Video and component SD/HD from 6G ‑ SDI input
Analog audio outputs: 2 channels of professional balanced analog audio with standard 1/4" jack connections
Digital audio outputs: 2 channels of professional balanced digital with standard 1/4" jack connections
SDI redundant input: automatically switches over if main SDI input is lost
Multi rate support: auto detection of SD, HD or 6G‑SDI
Updates and configuration: USB
Reclocking: yes

Standards

SD video standards: 525i 59.94 NTSC, 625i 50 PAL
HD video standards: 720p 50, 720p 59.94, 720p 60, 1080p 23.98, 1080p 24, 1080p 25, 1080p 29.97, 1080p 30, 1080p 50, 1080p 59.94, 1080p 60, 1080PsF 23.98, 1080PsF 24, 1080PsF 25, 1080PsF 29.97, 1080PsF 30, 1080i 50, 1080i 59.94, 1080i 60
2K video standards: 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
Ultra HD video standards: 2160p 23.98, 2160p 24, 2160p 25, 2160p 29.97, 2160p 30
4K video standards: 4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p

SDI compliance: SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE ST‑2081, ITU‑R BT.656 and ITU‑R BT.601
SDI video sampling: 4:2:2
SDI video rates: SDI video inputs are automatically detected between standard definition and high definition
SDI audio sampling: television standard sample rate of 48 kHz and 24 bit
SDI color precision: 4:2:2
SDI color space: YUV
SDI auto switching: auto detection of SD and HD
Analog color space: YUV
Analog color precision: 4:2:2

Format conversion

HD down conversion

Software

Software control: Mac and Windows software upgrade via USB
Internal software upgrade: via included updater application

Settings control

Mini switches or USB software

Power requirements

Power supply: +12 V universal power supply included with international socket adapters for most countries. Cable tie point
Power consumption: 8.04 W
Operational voltage range: 12 ‑ 31 V_DC

Operating systems
