SKU: H10878
EAN: 3662009019437
Audiophony PA - BM-SCAN
Background noise measuring device
Available
delivery is available for this product.
This item is currently in stock and will be shipped from our supplier's warehouse in Europe.
Free Shipping for order equal or above € 199 are limited for delivery within Europe
Variants of this product
874.50 €
Loop amplifier for surfaces of 1000 m2
148.00 €
Artificial hearing simulator for loop amplifier with headphone
282.50 €
Mobile induction loop kit for the hearing impaired people in places open to the public such as bank counters, ticket offices or post offices
332.00 €
Copper tape 100 m -18 mmWide x 0,1 mm thick
402.50 €
Magnetic induction loop kit system with counter Intercom with hearing aids
Product Details
Device to measure background noise and power of magnetic loops.
The BM-SCAN field strength meter has been designed to ensure that magnetic loop systems are installed and certified according to the new IEC 60118-4 standard. When these standards are met, the comfort of the userWill be identical wherever he/she uses a hearing aidWith the T position.
Technical characteristics
- Measuring range: -62 dB to +9 dB (0 dB = 400 mA/m)
- Peak factor: < 3
- Resolution: < 0.1 dB resolution for higher levels -32 dB
- Measurement resolution: 0.1 dB
- Detection type: RMS on all features
- Sensor: coil sensor
- Direction of sensitivity: in vertical position of the sensor (noted on the product)
- Calibration: calibrated at 1000 Hz (sine) read 0 dB at 5.03 mG
- Frequency response: flat ±1 dB from 50 Hz to 10 kHz
- Weighting: 2 meters specified in standard 61672-1
- Power source: battery (9 V) and external power outlet
- Headphone jack: weighted or flat output (selectable)
- Display: 16 x 2 LCD
- Backlight: blue LED (adjustable brightness)
