Beetek - G300-300USM-4LC + PCD380 BH03 kit

Kit consisting of 300 m fiber optic cable (G300-300USM-4LC) + cable reel (PCD380) + protective cap to protect the optical fiber (BH03).

G300-300USM-4LC

Armored fiber optic single-mode cable G657.A1 (9 / 125 μm) 4 cores designed with industry leading technology, 300 m length, LC connectors. Armored fiber optic cables, also known as armored sheath cables, are optical cables with an outer protective layer made of metallic materials and fibers. These layers provide mechanical protection against physical damage, moisture and other environmental factors, so they can withstand any harsh environment. Specially designed for the rental and outfitting industry.

Main features

• 4-core armored single-mode cable
• Flexible choice of LC, SC, ST or FC connectors (or combination of 1 - 6 types of connectors)
• The number of cores and length of the cable can be customized
• Branch length of 1 m
• 5 layers of armored steel ring, braided and aramid fiber structure
• Soft TPU sheath provides rodents-protection, high tensile and compression stress resistance
• Comes with two BH02 cable protectors
• Recommended to be used with Beetek cable reels

PCD380

Portable cable reel for fiber optic and network cables. Lightweight and rigid, specially designed for the rental and installation sectors.

Main features

• PP and ABS for environmental protection
• Its dimensions are suitable for storing 400 m of fiber optic or 300 m of network cable

BH03

BH03 is a medium aluminum clamshell-style cap to protect fiber optic and other types of cables during installations. It can be used with any cable with an outside diameter of up to 35mm. A simple yet effective product, specifically designed for the rental and stage industry to protect six-core fiber optic, CAT, SDI, HDMI, DP and other cables from harsh environments.

Technical characteristics

G300-300USM-4LC

• Lenght: 300 m
• Connector type: LC
• Connector color: dark blue
• Fiber type: single-mode G657.A1 (9 / 125 μm）
• Number of cores: 4
• Branch length: 1 m
• Structural layers: fiber core + core cladding + interior Kevlar reinforcement + TPU inner cladding + stainless steel
  armored tube + exterior Kevlar reinforcement + stainless steel braided shield + TPU outer jacket
• Jacket outer diameter: 6.2 mm ±0.1 mm
• Jacket color: gray
• Jacket material: matt frosted TPU
• Spiral tube diameter: 3.8 mm ±0.2 mm
• Spiral tube material: 304 stainless steel
• Core cladding diameter: 0.6 mm ±0.05 mm
• Core cladding material: LSZH
• Core diameter: 9 μm ±0.4 μm
• Transmission rate: 10 Gb/s within 2000 m
• Operating temperature: -20 to 70 °C

PCD380

• Large-sized cable reel
• Product material: ABS, PP
• Product color: black
• Turntable lock: yes
• Applicable products: fiber cable, CAT cable, AOC cable
• Applicable length: fiber cable & AOC cable: 400 m, CAT cable: 300 m
• Product size: 38 x 33 x 48.4 cm
• Product weight: 4.05 kg
• Package size: 40.5 x 31 x 51 cm
• Package weight: 5.3 kg

BH03

• Product material: aluminum alloy shell
• Product color: black
• Applicable products: fiber, CAT, HDMI / DP cables
• Maximum outer diameter: 35 mm
• Product structure: peanut shell structure (detachable design for easy installation)
• Customer logo: customization provided for 1000 pieces or more
• Size: 130 x 35 x 48.47 mm
• Weight: 56.6 g
