Blackmagic Design - Blackmagic Video Assist 7 12G HDR

Video Assist 7" 12G HDR by Blackmagic Design is a super bright 2500nit 7" HDR monitor that supports 3D LUTs and features professional scopes along with powerful focus assist and exposure tools that help you accurately set focus, exposure and frame shots. It adds professional monitoring and recording to any SDI or HDMI camera in all HD, Ultra HD, 2K and 4K DCI formats! The built in SD card recorder save files in broadcast quality 10-bit 4:2:2 ProRes or DNx formats, so you can start editing immediately without having to convert them! You also get two mini XLR connections with 48V of Phantom power and a noise floor of -128 dBV for high quality, crystal clear audio recording.

Connections

• SDI Video Inputs: 1
• SDI Video Outputs: 1
• SDI Rates: 270Mb, 1.5G, 3G, 6G, 12G.
• HDMI 2.0a Video Inputs: 1
• HDMI 2.0a Video Outputs: 1
• Analog Audio Inputs: 2 x balanced mini XLR with Phantom power
• Analog Audio Outputs: 1 x 3.5 mm headphone jack.
• Built in Speaker: Mono
• Screen Dimensions: 7 inch 1920 x 1200.
• Screen Brightness: 2500nits
• Screen Color: P3 wide color gamut
• SDI Audio Inputs: 16 channels embedded via 12G-SDI
• SDI Audio Outputs: 16 channels embedded via 12G-SDI
• HDMI Audio Inputs: 8 channels embedded via HDMI 2.0a
• HDMI Audio Outputs: 8 channels embedded via HDMI 2.0a
• Remote Control: 1 x 2.5 mm LANC for Record Start and Stop.
• SD Interface: Dual UHS-II SD slots
• Storage Type: Removable SDXC UHS-II, SDXC UHS-I and SDHC UHS-I SD cards. Supports DS, HS, SDR12, SDR25, DDR50, SDR50 and SDR104 SD cards.
• Computer Interface: 1 x USB Type-C 3.1 Gen 1 for external drive recording, initial setup, software updates and Video Assist Utility software control.
