Briteq - BTI-BLIZZARD WASH2s

The BTI-BLIZZARD WASH2s is an extremely powerful Wash light, designed to offer excellent performance both indoors and outdoors thanks to its IP65 protection and low noise operation.

This light is based on 19 x 50 W RGBL light sources, using lime instead of white for a wider color gamut and perfect white with a high color rendering index (CRI). It features various "Hi-CRI" color temperature presets, ranging from 1800 K to 10,000K, ensuring a very high and constant light output.

The BTI-BLIZZARD WASH2s features a very smooth 24-bit dimmer, available in fast and slow dimming modes, with four different dimming curves: linear, square, inverse square and S-curve. The RGB halo ring and RGB mask offer integrated "eye-candy" effects and 12-segment pixel control, further enriching the visual performance. The 16-bit Pan / Tilt movements are fast and precise, thanks to the position correction and speed channel. Additionally, new motors have been used for the zoom, which is now much faster.

This fixture also includes the super silent fan mode, making it ideal for theatrical applications. It is compatible with a wide range of control modes, from 26 to 133 DMX channels, and fully supports Art-Net and sACN. It also features a built-in wireless DMX receiver, compatible with W-DMX and CRMX, and a matrix LCD display that ensures easy navigation through the configuration menus.

The NFC function allows you to read error codes and other useful information, which is ideal for rental companies. Finally, the BTI-BLIZZARD WASH2s is equipped with Omega brackets for quick installation. An optional backup battery allows settings to be made without connecting the unit to the mains, adding further flexibility to the fixture.

Main features

• 19 x 50 W RGBL light sources
• IP65 protection and low noise operation: perfect for both outdoor and indoor use!
• Using lime instead of white for wider color palette
• Different “Hi-CRI” CCT presets from 1800 to 10,000 K
• Very high & constant light output: 52,000 lux @ 5 m (3.8°), 950 lux @ 5 m (38°)
• Very smooth 24 bit dimmer with fast and slow dimming mode
• Four dimmer curves: linear, square, inverse square, S-curve
• RGB halo-ring with nice build-in “eye-candy” effect macros
• RGB mask with 12 segment pixel control and build-in effect macros
• Fast 16 bit Pan/Tilt movements with position correction and Pan / Tilt speed channel
• DMX channels: 26 to 133
• RDM-functionality for easy remote setup
• Full support for Art-Net and sACN
• Pixels externally controllable with Art-Net or sACN while controlling the fixture with DMX
• Built-in wireless DMX-receiver (W-DMX / CRMX compatible)
• Matrix LCD-display assures easy navigation in the different setup menus
• NFC-function (dedicated APP still under development)
• 5-pin DMX in/outputs + RJ45 in/out + PowerCON TRUE1 compatible
• DMX IN / OUT can be very easily converted to 3-pin XLR with BT-XLR5TO3 kit
• Optional backup battery: settings can be made without connecting the unit to mains
• Super silent fan mode for theater applications
• Equipped with Omega brackets for fast installation

User benefits

• High light output: 52,000 lux at 5 m (3.8°) and 950 lux at 5 m (38°), ideal for large spaces and complex settings
• RGBL light source with 19 x 50 W LEDs
• Advanced pixel control: RGB halo ring and RGB mask with 12-segment control + integrated macro effects
• Very fast motorized zoom allows for both beam and wash effects, with smooth and precise transitions
• 24-bit dimmer with selectable curves
• Quick and silent movements
• IP65 rating
• Remote configuration: RDM and NFC support

Areas of use

• Theatre and musical performances
• Outdoor concerts and festivals
• Live events in large venues
• Trade fairs and scenic installations
• Discos and clubs
• Television broadcast
• Permanent indoor / outdoor installations
• Film sets

Technical characteristics

• Power input: 100 - 240 V_AC 50/60 Hz
• Power consumption: 1000 W
• Color: black
• Display: LCD
• Fixation: included omega bracket
• IP rating: outdoor
• Modes: stand-alone fixed, stand-alone automatic, manual, DMX
• Protocol: Art-Net, sACN, DMX, wireless DMX, RDM
• Programmable: yes
• Min. DMX channels: 26
• Max. DMX channels: 133
• Lux: 51,867 @ 5 m (beam 3.8°)
• Lumen: 8700
• Lamp: LED
• Min. color temperature: 1800 K
• Max. color temperature: 10,000 K
• CRI: 80
• Colors: lime, RGBL
• Mix colors: yes
• Functions: fast motorized zoom
• Beam angle: 3.8°
• Max. refresh rate: 25 kHz
• Input: 5-pin XLR, RJ45, RDM, powerCON TRUE1 or compatible
• Output: 5-pin XLR, RJ45, RDM, powerCON TRUE1 or compatible
• Dimensions: 42.1 x 31.6 x 48 cm
• Weight: 22.3 kg
