SKU: RE-101-4K22

EAN: 5060067155049

CYP - RE-101-4K22

Name: RE-101-4K22
Brand: CYP
SKU: RE-101-4K22
Price: 174 EUR
Availability: OutOfStock

Compact 4K HDMI repeater with EDID management, 18 Gbps signals support, custom EDID creation, stable 4K @ 60 4:4:4 extension up to 5 m

(0)

240.00 €

- 28%

174.00 €

Pay in 4 interest-free payments of 43.50 € with Discover More

Unfortunately, the quantity you have selected exceeds the amount available in stock. No problem! We will go ahead and send you the available quantity. We will then send you the reminder approximately within ten days.

Unfortunately, the quantity you have selected exceeds the amount available in stock.

Condition: New

I accept the general conditions and the privacy policy.

Not available.

delivery is not available for this product.

Free Shipping for order equal or above € 199 are limited for delivery within Europe

Variants of this product

CYP - PU-232

109.50 €

(0)

RS‑232 extender set over CAT5/6, full‑duplex transmission, hardware handshake, distances up to 250 m, simple hardware‑based operation with no configuration required

CYP - RE-EDID-4K22

209.50 €

(0)

Compact 4K HDMI EDID manager with HDCP mode control and downscaling, reliable 18 Gbps signal compatibility through custom, internal or bypass EDID configurations

CYP - PU-USB3-KIT

592.00 €

(0)

USB 3.2 Gen1 extender kit for long‑distance USB‑C/USB‑A device expansion up to 100 m

CYP - XA-3P

589.50 €

(0)

Battery‑powered 4K HDMI pattern generator, analyser and cable tester, 18 Gbps, HDCP 2.2, EDID management, SCDC monitoring, 4K > 1080p down‑scaling

CYP - XA-8P

749.00 €

(0)

8K HDMI pattern generator and analyser with 40 Gbps I/O, EDID management, HDR functions, HDCP/SCDC monitoring, OLED display

Product Details

HDMI repeater designed to regenerate, stabilize, and extend up to 5 additional meters of high-bandwidth 4K UHD HDMI signals at up to 18 Gbps. It supports HDMI 2.0, HDCP 1.4/2.2, and resolutions up to 4K @ 60 Hz 4:4:4.

It features an integrated EDID management system that allows you to quickly select between internal, external, or custom EDID. Using the optional PC software, you can create, edit, upload, or download custom EDIDs. The selector switch and LED indicators provide an instant view of the unit's status and the active EDID mode.

The repeater supports Deep Color up to 48-bit at 1080p and 36-bit at 4K, as well as pass-through for major audio formats, including LPCM 7.1, Bitstream, and HD Bitstream.

Main features

HDMI input and output with 18 Gbps (600 MHz) 4K UHD support
DVI 1.0 compatible with an HDMI-to-DVI adapter
HDCP 1.4 and 2.2 compliant
Supports HD resolutions up to 3840 × 2160 @ 60 Hz (4:4:4, 8-bit) and 4096 × 2160 @ 60 Hz (4:4:4, 8-bit)
48-bit Deep Color up to 1080p @ 60 Hz and 36-bit Deep Color up to 4K @ 60 Hz (YUV 4:2:0)
Supports LPCM 7.1, Bitstream, and HD Bitstream audio formats pass-through
Selectable EDID: internal, external, and custom
PC software for EDID management via port Micro-USB
LED display easily shows the current EDID and unit status

User benefits
