SKU: DN2-AV4K
EGO Display - AVMaster-4KNDI-D
NDI 5 / Dante AV-H to HDMI 2.0 / SDI decoder, UVC input, 4K resolution, PoE
Prime
fast delivery is available for this product.
This product is available in our warehouses in Italy, therefore it will be delivered within 2 - 5 working days.
Free Shipping for order equal or above € 199 are limited for delivery within Europe
Variants of this product
Bidirectional SDI to 2110 IP converter, 10G Ethernet, supports HD and Ultra HD standards to 2160p 60, 5 pin XLR talkback headset connection, DC power supply included
Bidirectional 16‑channel 12G‑SDI to SMPTE‑2110 converter, dual 100G Ethernet for full 2022‑7 redundancy, front‑panel monitoring, NMOS control
429.50 €
HDMI or VGA over IP receiver with USB support (4K, HDCP2.2, PoE)
Rack-mounted converter that transforms 12G-SDI and SMPTE-2110 IP signals into HDMI, Ultra HD support up to 2160p60, 3D LUTs, 10 XLR audio output, USB-C webcam
8‑channel SD/HD/Ultra HD up/down/cross converter, native 100G SMPTE‑2110 connectivity, full 2022‑7 redundancy, front‑panel monitoring for video and audio
Product Details
NDI 5 / Dante AV-H to HDMI 2.0 / SDI decoder on different formats, simultaneously. It receives an NDI 5 signal or Dante AV-H via an RJ-45 port and outputs an HDMI 2.0 signal with resolution up to 4096 x 2160p @ 50/60 fps and 3G-SDI. It offers the advantage of a low latency of 50 ms, a minimum bandwidth used in the network (compatible with 1 Gb switches) and a high quality transmission, adding the cross-domain connection function to not only improve interoperability between NDI devices, but also allow users to share video and audio more flexibly and quickly, creating a more complete NDI ecosystem.
It also has a UVC (USB Video Class) input on a USB 3.0 Type A port, used to connect devices such as webcams or video cameras via a USB connection, without the need to use additional converters.
It supports 4K 60 4:2:2 high definition video with minimal compression and extremely precise video and audio synchronization, making it ideal for permanent AV installations, concerts and sporting events, large exhibition halls and schools.
The output audio stream is embedded with the video on HDMI up to 8 channels, with 24-bit, 32 – 192 kHz format.
Power is provided by an external 12 VDC 2 A power supply, but also supports PoE. API integration via DANTE DIRECTOR software.
Ultimately, this unique device represents a flexible and cost-effective choice for large-scale events with dozens or even hundreds of AV processing devices.
Main features
- Up to 4K 60 4:2:2 resolution
- 1 Gb switch compatible
- 50 ms latency
- Simultaneous HDMI 2.0 and 3G SDI output
- Fully managed by Dante Controller
- NDI 5 license included
- Dante AV-H license included
- PoE power supply or external power supply
User benefits
- Max. 4K resolution
- Decoding of signals from DNI or Dante AV-H
- 3G-SDI output as well as HDMI
- Cross-domain connection
- UVC input for connecting devices such as webcams or video cameras
- API integration via DANTE DIRECTOR software
Areas of use
- Permanent video / audio installations
- Concerts and sporting events
- Large exhibition halls
- Education
- Corporate (video conferences and presentations)
- Places of worship
Technical characteristics
| Max. fps | 4096 × 2160p @ 50/60 fps |
| Recording mode | hardware compression |
| Video | |
| A/V input interfaces | video: 1 × RJ45 (RTSP / RTMP / HLS / TS / SRT / NDI HX support), 1 × USB 3.0 Type A (UVC) |
| A/V output interfaces | video: 1 × HDMI2.0 |
| Video feature | H.265 / H.264 / AVC, baseline / main / high profile supported HDMI output resolutions 4096 × 2160p @ 50/60 fps 4096 × 2160p @ 24/25/30 fps 3840 × 2160p @ 50/60 fps 3840 × 2160p @ 24/25/30 fps 1920 × 1080p @ 50/60 fps 1920 × 1080p @ 24/25/30 fps 1920 × 1080i @ 50/60 fps 1280 × 720p @ 50/60 fps 1280 × 1024p @ 60 fps 1280 × 960p @ 60 fps 1024 × 768p @ 60 fps 800 × 600p @ 60 fps 640 × 480p @ 60 fps 720 × 480p @ 60 fps 720 × 576p @ 50 fps |
| Video encode | N/C |
| Audio feature | AAC-LC configurable bit rate range from 32 kbps to 384 kbps sample rate: 16 bit 48 kHz |
| Network | |
| Network feature | 1 × RJ45 for 10/100/1000 Mbps Ethernet DHCP client |
| Support streaming protocol | NDI support Dante AV-H RTSP over UDP / TCP / Multicast / HTTP RTMP (Publish) TS over IP HLS |
| Misc | |
| Misc. features | UVC device supported web UI for system configuration firmware upgradable |
| PGM mode switch | N/C |
| Support record device | N/C |
| Power | |
| Power supply | USB 3.0 type-C power input support POE input |
