SKU: P3.9MG15I21

Yes Tech - P3.9 MG15 Indoor

Name: P3.9 MG15 Indoor
Brand: Yes Tech
SKU: P3.9MG15I21
Price: 570 EUR
Availability: OutOfStock

Quarter display indoor, IC ICN2153, SMD2020, full black LEDs, copper wire, 800 - 1000 nit, ≤3840 Hz, 250 × 500 mm, 4.2 kg

(0)

949.50 €

- 40%

570.00 €

Pay in 4 interest-free payments of 142.50 € with Discover More

Unfortunately, the quantity you have selected exceeds the amount available in stock. No problem! We will go ahead and send you the available quantity. We will then send you the reminder approximately within ten days.

Unfortunately, the quantity you have selected exceeds the amount available in stock.

Condition: New

I accept the general conditions and the privacy policy.

Not available.

delivery is not available for this product.

Free Shipping for order equal or above € 199 are limited for delivery within Europe

Variants of this product

Yes Tech - P3.9 MG12

508.50 €

(0)

Triangle display indoor, IC MBI5252, SMD2020, 800-1200 nit, ≤3840 Hz, 500x500 mm, 4 kg

Yes Tech - P3.9 Mwall

385.50 €

(0)

Indoor, fixed installation only, IC ICN2153, SMD2020, full black LEDs, copper wire, 800 - 1000 nit, ≤3840 Hz, 500 x 500 mm, 6 kg

Yes Tech - P3.9 MG11 Indoor

863.00 €

(0)

Right-angle display indoor, IC ICN2153, SMD2020, full black LEDs, copper wire, 800 - 1200 nit, ≤ 3840 Hz, 125 × 500 mm, 1.8 kg

Yes Tech - P3.9 MG6

275.00 €

(0)

B-STOCK Indoor, IC MBI5252, SMD2020, 800 - 1200 nit, ≤ 3840 Hz, 500 x 500 mm, 5.7 kg

Yes Tech - P3.9 Mwall

347.00 €

(0)

Indoor, fixed installation only, IC ICN2153, SMD2020, full black LEDs, copper wire, 800 - 1000 nit, ≤3840 Hz, 500 x 500 mm, 6 kg

Product Details

Right-angle shaped LED display (P3.9 MG15 Indoor), 3.9 mm pixel pitch, SMD2020, full black LED, ICN2153, for indoor use (800 - 1000 nits).

It is part of the MG Creative Extension series, which includes right angle, triangle and circular sector displays to make "Magic Stage" even more creative. This newly updated series will allow you to think and design the stage even more creatively, not only with the arc layout and presentation, but also polygon, sector, etc.

Combining the Magic Stage LED wall modules with the MG Creative Extensions which include rectangular (MG11), isosceles triangle (MG12), circular sector (MG13), right angle triangle (MG14), rectangle (MG15) LED displays, you can realize a variety of creative displays of the desired shape, such as numbers, letters, columns, Christmas tree, diamond, windmill, flower, heart, etc.

User benefits

Allows you to create LED walls of different shapes by combining the cabinets of the Magic Stage series

Areas of use

All those in which the Yes Tech LED displays of the Rental & Staging series are used

Technical characteristics

Module
LED encapsulation	2020
Pixel pitch	3.9 mm
Cabinet size	250 × 500 × 73 mm
Cabinet area	0.125 m²
Weight	4.2 kg/cabinet
Pixel density	65,536 dot/m²
IP grade	IP50
White balance brightness	800 - 1200 nit
Color temperature	6500 - 10,000 K adjustable
Horizontal viewing angle	160°
Vertical viewing angle	120°
Electrical parameters
Power consumption	420 / 140 W/m²
Working voltage	100 - 264 V_AC 50/60 Hz
Processing performance
Driving method	Constant drive
Scanning method	1/16 s
Frame frequency	50 & 60 Hz
Refresh frequency	1920 - 3840 Hz
Control system	Nova Star
Usage parameters
Life span	80,000 h
Working / storage temperature	-20 to 45 °C / -30 to 60 °C
Working / storage humidity	10 - 90% / 10 - 90% RH (no condensation)
Communication mode	CAT5
Certification	CE FCC ETL
